ESP Systems
and Solutions

We design and build our own ESP systems, since exceptional performance relies on attention to detail. Whatever your lifting challenge, Alkhorayef has a system available, or our specialists can engineer a solution that fits the bill.


High-performance ESP systems

The depth of our portfolio meets any – and every – ESP requirement. We offer the full set of ESPs, and accommodate the broadest range of flow rates and horsepower requirements.

PUMPS

Our multi-stage centrifugal pumps are available in either radial or mixed flow configuration. Proven to lift oil, water or brine while minimizing downtime, they include enhancement options for corrosive, abrasive and high load applications.

SPECTRUM ESP Pump Series
SPECTRUM Horizontal Pumping System

GAS MITIGATION

Deliver long periods of stable production by expelling free gas to the annulus, or pressurizing and homogenizing multiphase fluids before reaching the ESP. Our vortex separators and process units are engineered to perform effectively in abrasive and corrosive conditions.

Spectrum Gas Separator
Spectrum Gas Handlers

MOTORS

Our three-phase AC, two-pole, squirrel cage, induction motors are all individually hand-wound, and feature superior insulation, lubrication and heat dissipation as standard. They are available in a range of diameters with multiple horsepower, voltage and current nameplate options and rated up to 325°F (163°C).

SPECTRUM ESP Motor Series

PROTECTORS

Patented SPECTRUM ESP protector (seal) technology is engineered to maximize system run life; sealing against ultra-light well fluids and in extreme deviations. Additional performance enhancing options handle high horsepower, high head applications, and corrosive settings.

SPECTRUM ESP Protector

GAUGES

Respond to dynamic well conditions and fine-tune your ESP to ensure the pump operates at the best efficiency to maximum ESP run life and recovery from the reservoir. Our downhole monitoring systems provides fast, reliable data on reservoir and pump performance.

SPECTRUM ESP Downhole Monitoring Gauge

CABLES

Our high reliability ESP power cables are available in both circular and flat designs in a range of sizes. The engineering team can also advise you on the best cable configuration for your application, including HPHT and extended reach wells.

SPECTRUM ESP Cable Range

POWER CONTROL SYSTEMS

Modulate pump speed to extend the operating range of your ESP, and adapt to changing requirements. Our VSD systems also safeguard downhole equipment by providing electrical and mechanical soft-start features, electrical isolation and cleaner power output.

SPECTRUM Low Voltage VSD


HORIZONTAL PUMPING SYSTEMS

Horizontal pumping systems are efficient alternatives to positive displacement, split-case, and other surface pumping options. Delivering high performance over a wide flow rate range and minimal maintenance requirement. The APC Spectrum HPS is ideally suited for a range of applications in the oil and gas, industrial and mining markets.

SPECTRUM HPS System

Uneconomic reactive gassy well returned back to production

Case history

Parallel production via single wellbore maximizes performance

Case history

Longest running ESP in Sudan sets new record with 9.5 years of production

Case history
Vision Remote Well Monitoring Solution

Case history

Micro Emulsion Solution Integrated with Spectrum ESP Increases Oil Production by 400%

Case history

ESP solutions engineered for demanding requirements

Every day our tailor-made SPECTRUM ADVANCE ESP solutions are at work in the toughest production environments on the planet, including sour gas, deep, ultra-slim wells and high viscosity hydrocarbons.

Through our SPECTRUM ADVANCE tailored engineering services, Alkhorayef responds to clients’ unique application requirements, developing innovative engineered solutions that address more advanced challenges.

Expertly configured for harsh conditions, SPECTRUM ADVANCE solutions overcome these challenges to extract the greatest value throughout each well’s life.


Repeated ESP electrical failures in sour gas wells solved and leads to solution rollout to 50 wells.

Case history
